Home > products > Barium Fluoride > Cas7787-32-8 BaF2 Fluoride For Motor Brushes / Optical Crystal Lenses

Cas7787-32-8 BaF2 Fluoride For Motor Brushes / Optical Crystal Lenses

Product Details

Place of Origin: Jiaozuo City,China

Brand Name: Eversim

Certification: ISO 9001

Model Number: Barium Fluoride

Payment & Shipping Terms

Minimum Order Quantity: 1 Ton/Tons

Price: USD1300-2000 per ton

Packaging Details: 25kg or 50kg plastic woven bags lined with plastic bags or as demand

Delivery Time: 5-8 work days

Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability: 500 Ton/Tons per Month

Get Best Price
Highlight:

barium and fluorine

,

barium fluorine

Classification:
Halide (Except Chloride)
CAS No.::
7787-32-8
Place Of Origin::
China
Grade Standard::
Industrial Grade, Reagent Grade
Purity:
98%-99.9%
Appearance:
White Cubic Crystal/powder
Application:
Welding Flux,optical Glass
Melting Point::
1354°C
Molecular Weight::
175.324
Density:
4.83g/cm3
Classification:
Halide (Except Chloride)
CAS No.::
7787-32-8
Place Of Origin::
China
Grade Standard::
Industrial Grade, Reagent Grade
Purity:
98%-99.9%
Appearance:
White Cubic Crystal/powder
Application:
Welding Flux,optical Glass
Melting Point::
1354°C
Molecular Weight::
175.324
Density:
4.83g/cm3
Cas7787-32-8 BaF2 Fluoride For Motor Brushes / Optical Crystal Lenses

Manufacture price cas7787-32-8 BaF2 Barium fluoride for motor brushes, optical crystal lenses



Barium fluoride shows good optical transmission over wide spectrum range, which can be used as UV-IR windows in 0.15μm~0.25μm. It also presents excellent scintillation properties, which is widely used in high energy physics, nuclear physics and nuclear medical instruments ect.





Optical Properties
Transmission Range 150 nm to 14 μm
Transmittance >94% at 350 nm to 10.8 μm
Refractive Index

1.4624 at 2.58 μm

1.3936 at 10.35 μm

Reflection Loss

6.8% at 2.58 μm (both surfaces)

5.3% at 10.35 μm (both surfaces)

Radiation Length 20.6 mm
Residual Radiation Peak 47 nm
Emission Peak 310 nm slow; 220 nm fast
Decay Constant 620 ns slow; 0.6 ns fast
Light Output 20% slow; 4% fast
Absorption Coefficient 3.2 x 10-4 cm-1 at 6 μm
dn/dT -15.2 x 10-6 /°C
Physical Properties
Density 4.89 g/cm3
Melting Point 1280°C
Thermal Conductivity 11.72 Wm-1K-1 at 286K
Thermal Expansion 18.1 x 10-6 /°C at 273K
Knoop Hardness 82 with 500g indenter (kg/mm2)
Specific Heat Capacity 410J/(kg.k)
Dielectric Constant 7.33 at 1MHz
Youngs Modulus (E) 53.07 GPa
Shear Modulus (G) 25.4 GPa
Bulk Modulus (K) 56.4 GPa
Elastic Coefficient Elastic CoefficientElastic Coefficient
Apparent Elastic Limit 26.9 MPa (3900 psi)
Poisson Ratio 0.343
Chemical Properties
Solubility 0.0017 g/ 100g water at 23°C
Molecular Weight 175.36
Structure Cubic Crystal
Cleavage Plane (111)



Barium fluoride Intruduction:


1. CAS:7787-32-8
2. molecular formula: BaCO3
3. 99.2% Barium Carbonate
4. Excellent quality and best service



Barium fluoride Specification:

Optical Glass Optical Fiber Optical Coating Lens Prism Barium Fluoride BaF2



Barium fluoride Property:

Colorless cubic fine crystal,relative density:4.89, melting point:1355°C. Slightly soluble in hot water, soluble in acid and ammonium chloride. Toxic!



Barium fluoride Application:



Can be used in optical glass, ceramic pigment,

Can be used for glass fiber-optic, laser generator, and preservatives, such as flux.

Can be used for scintillation crystal, X-ray and high-energy particle detection.
